Atari 7800

Blue Arrow Company:  Atari, Inc
Blue Arrow Model Number:  CX7800
Blue Arrow Manufacture Date/Year:  1987


Blue Camera Camera Used:  Nikon D5100
Blue Info Images Copyright:  Click Here
Atari 7800 front Atari 7800 back Atari 7800 side1 Atari 7800 side2
Atari 7800 herol Atari 7800 heror Atari 7800 top1 Atari 7800 top2


Blue Arrow Specifications

Core Unit:

  • Processor:  1.79 MHz Atari SALLY 6502 ("6502C")
  • RAM:  4 KB
  • Graphics:
    • MARIA custom graphics controller
    • 160 X 240 (160 X 288 PAL) resolution or 320 X 240/288 resolution
    • 256 color palette out of 256 colors (16 hues * 16 luma)
    • Different graphics modes restricted the number of usable colors and the number of colors per sprite
    • Direct Memory Access (DMA)
    • 7.16 MHz graphics clock
  • Sound:
    • TIA (Television Interface Adaptor "Stella") video and sound chip
    • Video and sound chip is same as the Atari 2600
    • Only the sound is used in 7800 games
    • Both video and sound are used in Atari 2600 games
  • Controller Ports:  2
  • Expansion Ports:  1
Standard Controllers:
  • CX24 Pro-Line Joystick Controller



Atari 7800 Joystick
Pro-Line Joystick Controller

Game Format:
  • 7800 ROM Cartridge (Up to 48K)
  • 2600 ROM Cartridge (1K to 4K)



Atari 7800 Cartridge
Typical 7800 Game Cartridge

Physical Dimensions:
  • Size (Inches):  3.25 H x 11.5 W x 8.5 D


Blue Camera Camera Used:  Nikon D5100
Blue Info Images Copyright:  Click Here
Atari 7800 n1 Atari 7800 n2 Atari 7800 n3 Atari 7800 n4
Atari 7800 n5
